Size (mm) |
D (mm) |
D1 (mm) |
L (mm) |
L1 (mm) |
Ring | Pin |
Weight (g) |
||
---|---|---|---|---|---|---|---|---|---|
6 |
20 |
11.5 |
30 |
4.0 |
BA.15B |
GA.15B |
40 |
||
7 |
20 |
12.5 |
30 |
4.0 |
BA.15B |
GA.15B |
45 |
||
8 |
20 |
14.0 |
30 |
5.2 |
BA.15B |
GA.15B |
45 |
||
9 |
20 |
15.0 |
30 |
5.0 |
BA.15B |
GA.15B |
45 |
||
10 |
20 |
16.5 |
30 |
6.0 |
BA.15B |
GA.15B |
45 |
||
11 |
20 |
17.5 |
30 |
7.0 |
BA.15B |
GA.15B |
50 |
||
12 |
20 |
19.0 |
30 |
8.0 |
BA.15B |
GA.15B |
50 |
||
13 |
22 |
20.0 |
30 |
8.0 |
BA.18B |
GA.18B |
50 |
||
14 |
22 |
21.5 |
30 |
10.0 |
BA.18B |
GA.18B |
65 |
||
15 |
22 |
22.0 |
30 |
10.0 |
BA.18B |
GA.18B |
70 |
||
16 |
22 |
24.0 |
30 |
10.0 |
BA.18B |
GA.18B |
70 |
||
17 |
22 |
26.0 |
30 |
10.0 |
BA.18B |
GA.18B |
70 |
||
18 |
22 |
26.0 |
30 |
12.0 |
BA.18B |
GA.18B |
75 |
||
19 |
22 |
27.8 |
30 |
12.0 |
BA.18B |
GA.18B |
80 |
L (mm) |
D (mm) |
Ring | Pin |
Weight (g) |
||
---|---|---|---|---|---|---|
75 |
19 |
BA.16A |
GA.15A |
95 |
||
150 |
19 |
BA.16A |
GA.15A |
170 |
Standards: NF ISO 1711-2, ISO 1711-2, DIN 3121
Safety first: always use locking rings and pins.
For 1/2" - 12.7 bits.
Weight: 45g.
