SNAP-ON (John Bean) B1200P CAR WHEEL BALANCER

CAR WHEEL BALANCER

WITH NON-CONTACT DATA ENTRY AND DIAGNOSTIC FUNCTIONS

The wheel balancer with diagnostic functions for tyre shops, garages and car dealerships with high tyre service volume. With touchscreen monitor and automatic non-contact data entry. Unbalance measurement and run-out diagnosis are performed in a single fast measuring run.

MAIN FEATURES

High-productivity wheel balancer
Rim scanner for
- automatic non-contact rim profiling
- automatic selection of balancing mode and weight position
- automatic acquisition of rim diameter and offset
Smart Sonar for automatic non-contact acquisition of rim width
Run-out diagnosis combined with unbalance measurement in a single fast measuring run
Recommendation for match-mounting, when possible, to reduce vibrations caused by radial run-out
Touchscreen monitor with graphical user interface PLATINUM – fast and very intuitive
easyWeight: fast pinpoint bottom weight placement. Pinpoint laser light indicator to accurately position adhesive weights on the wheel
Stop-in-Position feature where the operator only has to touch the amount of unbalance on the screen and the wheel is automatically indexed to correction position
Torque-controlled Power Clamp device – fast and accurate clamping of the wheel
QuickBal for reduced measurement time:
Short start-stop cycle time: 4.5 seconds (15" rim)
VPM measurement technique for uncompromised accuracy
Rim lighting to facilitate rim cleaning and speed up data entry and weight positioning
Imbalance minimisation and optimisation programs
Networking capability with the optional networking software
Compatible with asanetwork
Print-out with optional printer

INNOVATIVE FEATURES

PLATINUM TOUCH SCREEN USER INTERFACE

Highly intuitive and fast touch-screen monitor with large digits, coloured weight position indicators and PLATINUM user interface – improved intuitiveness and ergonomics.

VPM TECHNIQUE

Measurement system for high precision and repeatability. Ensures most accurate balance results and is insensitive to ambient conditions.

easyWEIGHT™

Pinpoint laser identifies exact weight placement location for increased accuracy and efficiency.

POWER CLAMP™

The patented electro-mechanical Power Clamp™ device clamps the wheel accurately with a constant force, which is most important for every balancing operation.

SPLIT WEIGHT MODE

Hides adhesive weights behind two adjacent spokes so they cannot be seen from the outside.

easyALU™

Touch the rim with the gauge arm to enter the rim dimensions and automatically select the weight balancing mode.

QuickBAL™

30% reduced cycle time, less than 4.5 seconds, maintaining the same high accuracy.

STOP IN POSITION

Touch the screen to automatically rotate the wheel to weight application position.

RIM SCANNER

The rim scanner automatically detects rim diameter and offset as well as the number and position of rim spokes. Then it automatically chooses balancing mode, weight types and weight positions.

Smart Sonar™

Automatic, non-contact rim width acquisition delivers greater accuracy and ease of use for a 30% savings in complete process when compared to manual operation.

RADIAL RUN-OUT

Peak-to-peak and 1st harmonic graphs of wheel run-out are provided for an easy diagnostic of the issues. Rim run-out and matching information are provided when necessary.

LED WHEEL LIGHTING

Bright LED lighting system that facilitates rim cleaning and aids in the weight positioning process.

Catalogs:

B1200P

Productivity and diagnostics

Specifications:

	SNAP-ON (John Bean) B1200P
Vehicles supported	Cars / Light trucks / SUVs
Measuring speed	< 200 rpm
Balancing accuracy	1 g
Angular resolution	0.7 °
Start/Stop balancing time (wheel 195/65R15)	up to 4.5 s
Diameter of shaft	40 mm
Length of shaft	225 mm
Dimensions L x W x H	1362 x 1001 x 1895 mm
Net weight	130 kg
Power supply	230 V 1ph 50/60 Hz
MAXIMUM WHEEL DIMENSIONS
Max. wheel diameter	1050 mm
Wheel width	76 - 508 mm
Max. wheel weight	70 kg
AUTOMATIC DATA ENTRY
Rim diameter	14 - 26"
Rim width	3 - 15.8"
Automatic spoke counting	•
MANUAL DATA ENTRY
Rim diameter	8 - 32"
Offset	1 - 20"
Rim width	1 - 20"
