SNAP-ON (John Bean) B400L CAR WHEEL BALANCER

CAR WHEEL BALANCER

WITH MONITOR

The wheel balancer for tyre shops, car dealerships and garages with medium tyre service volume: with the easyWeight pinpoint indicator light – an accurate, fast and easy solution to position adhesive weights on the wheel.

MAIN FEATURES

High-productivity wheel balancer
Monitor with graphical user interface SILVER – improved intuitiveness and ergonomics
easyWeight: Pinpoint laser light indicator to accurately and conveniently position adhesive weights on the wheel.
Semi-automatic input of offset and rim diameter via 2D SAPE and automatic rim width acquisition via Smart Sonar – fast and easy
Semi-automatic pre-selection of balancing mode via easyAlu
VPM measurement technique for uncompromised accuracy
QuickBal for reduced measurement time:
Short start-stop cycle time: 4.5 seconds (15" rim)
New ergonomic weight tray

VPM TECHNIQUE

Measurement system for high precision and repeatability. Ensures most accurate balance results and is insensitive to ambient conditions.

easyWEIGHT™

Pinpoint laser identifies exact weight placement location for increased accuracy and efficiency.

SPLIT WEIGHT MODE

Hides adhesive weights behind two adjacent spokes so they cannot be seen from the outside.

GAUGE ARM

Measuring arm with integrated weight holder for easy application of adhesive wheel weights.

easyALU™

Touch the rim with the gauge arm to enter the rim dimensions and automatically select the weight balancing mode.

QuickBAL™

30% reduced cycle time, less than 4.5 seconds, maintaining the same high accuracy.

Smart Sonar™

Automatic, non-contact rim width acquisition delivers greater accuracy and ease of use for a 30% savings in complete process when compared to manual operation.

OVERSIZE SHAFT

The shaft of 225 mm allows the use of stud-hole flanges and other accessories for almost every type of rim.

Catalogs:

B300, B400, B500, B600

Productivity wheel balancers

Specifications:

	SNAP-ON (John Bean) B400L
Vehicles supported	Cars / Light trucks / SUVs
Wheel clamping	Quick nut
Measuring speed	< 200 rpm
Balancing accuracy	1 g
Angular resolution	± 0.35°
Start/Stop balance time - Check spin	4.5 s
Diametre of shaft	40 mm
Lenght of shaft	225 mm
Dimensions LxWxH	1313 x 868 x 1834 mm
Net weight	115 kg
Input power (VAC)	230 VAC 1ph 50/60 Hz
MAXIMUM WHEEL DIMENSIONS
Max. wheel diameter	1050 mm
Wheel width	76 - 508 mm
Max. wheel weight	70 kg
SEMI-AUTOMATIC DATA ENTRY (SAPE)
Rim diameter	8 - 25"
Rim width	3 - 15"
MANUAL DATA ENTRY
Rim diameter	8 - 32"
Offset	1 - 20"
Rim width	1 - 20"
