SNAP-ON (John Bean) B9280 TRUCK WHEEL BALANCER WITH MONITOR

TRUCK WHEEL BALANCER WITH MONITOR

The truck wheel balancer b9280 measures both the static and the dynamic portion of unbalance and hence increases truck wheel life considerably. The balancer is equipped with a wide-screen monitor and asanetwork capability.

MAIN FEATURES

Automatic input of offset and rim diameter (2D SAPE)
Input of rim width via capacitive keypad
Electronic friction brake to retain the wheel in any position
Virtual plane imaging (VPM) technique
Weight tray with 27 weight compartments and shelves for car cones and weight pliers
Measuring speed less than 100 rpm
Automatic braking of the wheel after measurement
Automatic static and dynamic unbalance measurement in a single measuring run
Cone adaptor with spacer and light-truck cone of 120 – 170 mm diameter
Gauge arm with patented wheel weight clamp to input wheel data and position adhesive weights
Hidden weight mode
Patented optimisation mode
19" TFT wide-screen monitor
Comprehensive on-line help in more than 25 languages
asanetwork capability

GAUGE ARM

Measuring arm with integrated weight holder for easy application of adhesive wheel weights.

VPM TECHNIQUE

Measurement system for high precision and repeatability. Ensures most accurate balance results and is insensitive to ambient conditions.

QuickBAL™

30% reduced cycle time, less than 4.5 seconds, maintaining the same high accuracy.

USER-FRIENDLY INTERFACE

Easy to operate - with on-line help in more than 25 languages.

Catalogs:

Truck Wheel Balancers

The complete series

Specifications:

	SNAP-ON (John Bean) B9280
Diametre of shaft	40 mm
Measuring speed	< 100 rpm
Balancing accuracy	1 g
Lenght of shaft	40 mm
Rim diameter range	8 - 26"
Rim width range	2 - 20"
Max. wheel diameter	1300 mm
Max. wheel weight	250 kg
Input power	230 VAC 1ph 50/60 Hz
Dimensions LxWxH	1370 x 1455 x 2005mm
Net weight	238 kg
