SAMOA 353120 |
|---|---|
| Pressure ratio | 3:1 |
| Air piston diameter (mm) | 51 |
| Air piston stroke (mm) | 75 |
| Maximum free flow capacity (l/min) | 35 |
| Air pressure range (bar) | 3 - 10 |
| Maximum fluid pressure (bar) | 30 |
| Air inlet (F) (BSPT) | 1/4 |
| Fluid outlet (F) (BSP) | 1/2 |
| Noise level (dB) | 80 |
| Application | Universal stub pump |
| Total height (A) (mm) | 495 |
| Pump tube height (D) (mm) | 200 |
| Pump tube diameter (C) (mm) | 34 |
| Gross weight (kg) | 2 |
