High pressure, 60:1 pressure ratio, air operated grease pumps.
They can be connected to a compressed air line or to the air brake circuit of a commercial vehicle.
Delivery: 1 cc each time the trigger is pressed.
Maximum air pressure: 10 bar, Air connection thread 1/4" BSP (F).
Includes a 1000 cc barrel with an air driven grease follower.
Recommended for high viscosity grease and low temperatures.
Supplied with 400 mm double steel braid reinforced outlet hose with 4 jaw connector (PN 141 040) and filler nipple.
Bulk grease loading using a grease filler pump.
Heavy duty high capacity grease pump with 3 alternative lever positions
Can be used under any operating conditions and with all type of lubricants (winter/summer, high or low viscosity grease, oil).
Maximum pressure range between 175 to 350 bar (2500 to 5000 psi)
With a delivery of 20 gr, 15 gr or 10 gr per stroke depending on the position of the lever chosen.
Steel and leak proof 16 Kg container with oval shape for easy handling and stability.
Pump includes 1.5 m high pressure hose with a 3-jaw hydraulic connector.
