FACOM 3/4" DRIVE METRIC 6-POINT IMPACT SOCKETS

3/4" DRIVE METRIC 6-POINT IMPACT SOCKETS

Standards: NF ISO 2725-2, NF ISO 1711-2, ISO 2725-2, ISO 1711-2, DIN 3129, ASME B107.33
For your safety, use impact sockets and accessories with the appropriate rings and pins.

	Size (mm)	D (mm)	D1 (mm)	L (mm)	L1 (mm)	Ring	Pin	Weight (g)
FACOM NK.17A	17	38	28.5	50	14	BA.30B	GA.31B	300
FACOM NK.18A	18	38	29.0	50	14	BA.30B	GA.31B	310
FACOM NK.19A	19	38	29.5	50	14	BA.30B	GA.31B	315
FACOM NK.21A	21	38	32.0	50	14	BA.30B	GA.31B	330
FACOM NK.22A	22	38	34.0	50	14	BA.30B	GA.31B	345
FACOM NK.23A	23	38	35.0	50	17	BA.30B	GA.31B	350
FACOM NK.24A	24	38	36.0	50	17	BA.30B	GA.31B	350
FACOM NK.26A	26	38	38.0	52	18	BA.30B	GA.31B	480
FACOM NK.27A	27	38	42.0	52	18	BA.30B	GA.31B	480
FACOM NK.28A	28	38	42.0	52	18	BA.30B	GA.31B	520
FACOM NK.29A	29	38	42.0	52	18	BA.30B	GA.31B	520
FACOM NK.30A	30	38	42.0	52	20	BA.30B	GA.31B	545
FACOM NK.32A	32	38	46.0	55	22	BA.30B	GA.31B	620
FACOM NK.33A	33	44	48.0	57	22	BA.30B	GA.31B	650
FACOM NK.34A	34	44	48.0	57	22	BA.30B	GA.31B	680
FACOM NK.35A	35	44	50.0	57	24	BA.30B	GA.31B	680
FACOM NK.36A	36	44	52.0	57	24	BA.30B	GA.31B	705
FACOM NK.38A	38	44	56.0	57	26	BA.30B	GA.31B	890
FACOM NK.41A	41	44	58.0	63	27	BA.30B	GA.31B	890
FACOM NK.42A	42	44	62.0	63	27	BA.30B	GA.31B	925
FACOM NK.46A	46	44	65.0	68	30	BA.30B	GA.31B	1000
